General
- Product Color : Moon Ray, Midnight Sky, Marantz Champagne
 - Included : Certificate of Authenticity, QSG, Power Cable, HDMI Cable
 - User Interface : Volume up/down, Play / Pause, Multi colored LED status indicator, Connect button (rear), Bluetooth button (rear)
 - Dimensions (h × w × d) Inches : 19.41 × 10.04 × 20.83
 - Dimensions (h × w × d) mm : 493 × 255 × 529.2
 - Weight (lbs) : 46.9
 - Weight (kg) : 21.3

Amplifier
- Total Amplifier Power (FTC) : 370W (FTC Power Output Rating)
 - Total Amplifier Power (Peak) : 860W (This rating was not tested under the FTC standard)
 - Total Amplifier Power (Peak, Raw Amplifier Power) : 1400 W (This rating was not tested under the FTC standard)
 - Amplifier Toplogy : Marantz Rise GaN FET

Loudspeaker Array
- Bass : 1×8" Marantz Gravity
 - Wideband : 4×3"
 - High Frequency : 3×1"

Performance
- Frequency Response : 28Hz to 20kHz (+/-3dB), 18Hz (-10dB)
 - Maximum SPL : 111dB (1M)
 - Peak SPL : 122dB (1M)

Audio Connectivity
- Analog : 1 pr. RCA L/R
 - Digital : 1 ea. TOSLINK Optical
 - USB : 1 ea. USB-C (Mass Storage)
 - HDMI : 1 ea. eARC / ARC

Audio Format Support
- Decoding : Dolby Atmos, Dolby TrueHD, DSD Dolby Digital+, Dolby Digital, LPCM
 - Max PCM Sample Rate / Bit Depth : Stereo: 192kHz / 24 bit, Multi-Channel: 192kHz / 24 bit (7.1 Channel)
 - Max DSD Data Rate : 5.6 MHz (DSD ×2)
 - Stereo File Formats (HEOS network share or USB) : WMA: up to and including 192 kbps, AAC & MP3: up to and including 320 kbps, WAV, ALAC, FLAC: up to and including 24-bit/192kHz, DSD: 2.8 MHz, 5.6MHz

Streaming Technologies
- Bluetooth : BT 5.4
 - AirPlay : AirPlay 2
 - Spotify : Spotify Connect

Music Services and Sources
- Music Services Supported (HEOS, subject to change and local availability) : Pandora, Spotify, TuneIn, SiriusXM, Amazon Music, TIDAL, iHeartRadio, Deezer, Deezer HiFi, Mood:Mix, Sony Hi-Res, AWA, Play, SoundCloud.
 - Music stored on mobile device : Yes (iOS, Android, or Kindle Fire)
 - NAS (Network Attached Storage) : Network share, UPnP
 - USB Storage Device Playback : Yes (FAT32, NTFS formatted drives)

Networking & Control
- Wired Connectivity : Ethernet
 - Wireless Connectivity : Dual band, 802.11 a/b/g/n/ac/ax
 - Control System Compatibility via TCP/IP : Crestron, Control4, AMX
 - HEOS App : iOS, Android, Kindle Fire
