General
- Product Color : Moon Ray, Midnight Sky, Marantz Champagne
- Included : Certificate of Authenticity, QSG, Power Cable, HDMI Cable
- User Interface : Volume up / down, Play / Pause, Multi colored LED status indicator, Connect button (rear), Bluetooth button (rear)
- Dimensions (h × w × d) Inches : 14.33 × 8.27 × 15.26
- Dimensions (h × w × d) mm : 364 × 210 × 387.5
- Weight (lbs) : 27.5
- Weight (kg) : 12.5
Amplifier
- Total Amplifier Power (FTC) : 310 W (FTC Power Output Rating)
- Total Amplifier Power (Peak) : 745 W (This rating was not tested under the FTC standard)
- Total Amplifier Power (Peak, Raw Amplifier Power) : 1160 W (This rating was not tested under the FTC standard)
- Amplifier Toplogy : Marantz Rise GaN FET
Loudspeaker Array
- Bass : 1×6.5" Marantz Gravity
- Wideband : 3×2"
- High Frequency : 2×1"
Performance
- Frequency Response : 30Hz to 20kHz (+/-3dB), 22Hz (-10dB)
- Maximum SPL : 104dB (1M)
- Peak SPL : 114.5dB (1M)
Audio Connectivity
- Analog : 1 pr. RCA L/R
- Digital : 1 ea. TOSLINK Optical
- USB : 1 ea. USB-C (Mass Storage)
- HDMI : 1 ea. eARC / ARC
Audio Format Support
- Decoding : Dolby Atmos, Dolby TrueHD, DSD Dolby Digital+, Dolby Digital, LPCM
- Max PCM Sample Rate / Bit Depth : Stereo - 192kHz / 24 bit; Multi Channel - 192kHz / 24 bit (7.1 Channel)
- Max DSD Data Rate : 5.6 MHz (DSD ×2)
- Stereo File Formats (HEOS network share or USB) : WMA - up to and including 192 kbps; AAC & MP3 - up to and including 320 kbps; WAV, ALAC, FLAC - up to and including 24 bit/192kHz; DSD - 2.8 MHz, 5.6MHz
Streaming Technologies
- Bluetooth : BT 5.4
- AirPlay : AirPlay 2
- Spotify : Spotify Connect
Music Services and Sources
- Music Services Supported (HEOS, subject to change and local availability) : Pandora, Spotify, TuneIn, SiriusXM, Amazon Music, TIDAL, iHeartRadio, Deezer, Deezer HiFi, Mood:Mix, Sony Hi-Res, AWA, Play, SoundCloud.
- Music stored on mobile device : Yes (iOS, Android, or Kindle Fire)
- NAS (Network Attached Storage) : Network share, UPnP
- USB Storage Device Playback : Yes (FAT32, NTFS formatted drives)
Networking & Control
- Wired Connectivity : Ethernet
- Wireless Connectivity : Dual band, 802.11 a/b/g/n/ac/ax
- Control System Compatibility via TCP/IP : Crestron, Control4, AMX
- HEOS App : iOS, Android, Kindle Fire
